219mm Automatically Pipeline internal corrosion inspection robot NDT Pipeline Smart Pig

Product Categories
Xi'an Snake Pipe Robot Technology Co., Ltd
Contact Now

219mm Automatically Pipeline internal corrosion inspection robot NDT Pipeline Smart Pig

  • 1
  • 2
  • 3

Brand Name : Snake

Model Number : SNK-ICR219

Certification : Yes

Place of Origin : China

MOQ : 2 Set

Price : USD

Payment Terms : T/T

Supply Ability : 1000 Set

Delivery Time : 20-30 work days

Packaging Details : Poluurethane box

Name : Inspection robot

Material : Metal pipe

Method : ECT

Color : Stainless steel

Contact Now

219mm Automatically Pipeline internal corrosion inspection robot NDT Pipeline Smart Pig

Product description

219mm Pipeline Smart Pig is using ECT method,which is an intelligent pipeline internal corrosion robot,NDT pipeline smart pig.Robot is walking in the pipeline by pressure of fluid. During walking, the corrosion situation of the inner wall of the pipe is collected and recorded by robot;and data is analyzed and explained by special software, inspection report and conclusion are finally formed.

Using ECT inspection method, detecting corrosion in pipeline.The severity of corrosion in the pipeline can be qualitatively judged through special data and software analysis, to guide the management department for maintaining and managing.

Technical specification

Item Specifications
Pipeline Internal Diameter Range 60mm~273mm
Defect Type Uniform corrosion, corrosion pits, corrosion perforation and cracks
Distance Range 0~10km
Traffic ability

Min Bending Diameter1.5D

Inner Diameter Variation±10%
Working Temperature Range -20~60°C
Pressure Resistance 10Mpa
Detection Speed <2km/h
Battery Life 2-3 years
Pipeline Type Oil, gas, water
